copper

• Diameter from 2mm to 50mm. Length from 0.1 meter to 2 meters.

• Areas of application: heating and cooling technology (heating and cooling elements); Building (as decoration for interior lining and facades); electric lines; wire windings and chokes/coils.

• If your desired length/width is not listed, select the next larger length/width. Leave a comment on your order with the length/width you want. We cut according to your measurements.

• Dimensional tolerances: +/-2mm.

• Didn't find the sizes you wanted? Just contact us! We are happy to help you with your request.

• Cu-ETP; EN CW004A.

• Diameter from 0.1mm to 5mm. Length from 2 meters to 750 meters.

• Areas of application: Hobby area & handicrafts; Decoration; Windings & electrical conductors; Contacts, terminals & switches.

• Density 8.93 g / cm³; Melting point 1083 ° C; Thermal conductivity 394 W / (m · K); electr. Resistance 0.018 Ω mm² / m; electr. Conductivity 57 S / m.

• Dimension tolerances: +/- 2mm.

• Diameter: 0.05mm-5mm. Length: 2-750m.

• Areas of application: model making; Construction of electric coils; Construction of transformers and machines; Manufacture of high frequency stranded wire.

• Wnr. 2.0090; EN Cu-DHP; UNS C12200.

• Electrical resistance 0.022 Ω mm² / m; electr. Conductivity 45 m / Ω • mm²; Thermal conductivity 305 W / (m · K).

• Didn't find the sizes you wanted? Just contact us! We are happy to help you with your request.

• CW004A (Cu-ETP - 2.0065);

• Applications: construction (waterproofing, roof and wall cladding); sewage pipes and pipes for cold and hot water installations and heating devices; Manufacture of gutters and downpipes; Production of roof drainage; Manufacture of copper vessels; various household metal goods;

• Properties: very good weldability, soft solderability and hard solderability; excellent resistance to drinking and service water; very good cold formability and good hot formability; insensitive to non-oxidizing acids and neutral salt solutions; good for polishing, electroplating and tinning; excellent longevity;

• density 8.94 g/cc; melting point 1083 °C; thermal conductivity 305 W/mK; tensile strength 240-300 N/mm²;

• Available cut or made to measure.

• CW004A (Cu-ETP - 2.0065);

• Applications: construction (waterproofing, roof and wall cladding); sewage pipes and pipes for cold and hot water installations and heating devices; Manufacture of gutters and downpipes; Production of roof drainage; Manufacture of copper vessels; various household metal goods;

• Properties: very good weldability, soft solderability and hard solderability; excellent resistance to drinking and service water; very good cold formability and good hot formability; insensitive to non-oxidizing acids and neutral salt solutions; good for polishing, electroplating and tinning; excellent longevity;

• density 8.94 g/cc; melting point 1083 °C; thermal conductivity 305 W/mK; tensile strength 240-300 N/mm²;

• Available cut or made to measure.

Copper pipe 3x0.5mm-54x1.5mm rod 2.0090 Aisi C11000 heating drinking water 0.1-2 meters

• Cu-ETP; CW004A.

• Possible uses: clamps and stranded wires; electrical conductors and contacts; housings for electrical appliances; coils and choke; water heater; as snail protection for flower pots

• Properties: excellent electrical and thermal conductivity; excellent resistance to sea air, drinking and service water, non-oxidizing acids and alkalis; good cold and hot forming; not suitable for sweating; not machinable.

• Density ‎8.93 g/cm³; melting point 1083 °C; tensile strength 200 - 260 N/mm²; Condition R220 (soft).

• thermal conductivity 394 W/mK; electrical conductivity 57 Ms/m; electr. Resistance 0.018Ω mm²/m.

• Applications: filigree handicrafts; Electronics; Jewelry making; Decoration.

• Elongation at break 0.1mm - 19.3% -20.9%; 0.2mm - 21.8% -22.3%; 0.3mm - 22% -22.8%; 0.4mm - 22.3% -22.8%; 0.5mm - 22.2% -22.9%; 0.6mm - 22.1% -22.9%; 0.7mm - 22.5% -23.0%; 0.8mm - 22.3% -23.1%; 1.0mm - 22.5% -23.1%.

• Purity of the silver at least 99%; Silver layer approx. 0.5 μm.

• Surface smooth.

Constantan wire Ø0.04-0.45mm resistance wire 2.0842 CuNi44 heating wire 2.5-100 meters

• copper content - 99.9%;

• Fields of application: Metallurgy and chemical industry (as alloy additive and catalyst); automotive industry (rocks, brake pads); Welding technology (current nozzles, welding electrodes, soldering tips); glass, ceramics, enamel (as pigment); paints and varnishes (as pigment); electronics (multilayer conductor tracks); as metal coating; shipbuilding (antifouling coating);

• Properties: non-toxic; not explosive; non-flammable and combustible; very good bulk density;

• bulk density 1.25 - 2.0 g/cm³; Grain size <33 m="" --30--="">

• CW004A (Cu-ETP - 2.0065);

• Applications: construction (waterproofing, roof and wall cladding); sewage pipes and pipes for cold and hot water installations and heating devices; Manufacture of gutters and downpipes; Production of roof drainage; Manufacture of copper vessels; various household metal goods;

• Properties: very good weldability, soft solderability and hard solderability; excellent resistance to drinking and service water; very good cold formability and good hot formability; insensitive to non-oxidizing acids and neutral salt solutions; good for polishing, electroplating and tinning; excellent longevity;

• density 8.94 g/cc; melting point 1083 °C; thermal conductivity 305 W/mK; tensile strength 240-300 N/mm²;

• Available cut or made to measure.

• Diameter: 0,1 - 0,2 mm. Length: 2-200m.

• Areas of application: manufacture of measuring devices and precision resistors; as measuring line in cryostats; production of shunts.

• Wnr. 2.1362; EN CuMn12Ni.

• electrical resistance 0.43 Ω mm²/m; Thermal conductivity 22 W/(m K).

• Didn't find the sizes you wanted? Just contact us! We are happy to help you with your request.

Copper square 6x6-40x40mm copper square bar 2.0065 square bar Cu-ETP

• Fields of application: Electrical industry; mechanical engineering; chemical industry; gas and water installation; heating and air conditioning technology; plant and apparatus engineering;

• Properties: good durability; high corrosion resistance; very good weldability and brazeability; good thermal conductivity; excellent formability; good electrical conductivity;

• length tolerance +/-3mm.

• Didn't find the sizes you are looking for? Just contact us! We will be glad to help you with your request.

• (Cu-ETP - 2.0065);

• Applications: construction (waterproofing, roof and wall cladding); sewage pipes and pipes for cold and hot water installations and heating devices; Manufacture of gutters and downpipes; Production of roof drainage; Manufacture of copper vessels; various household metal goods;

• Properties: very good weldability, soft solderability and hard solderability; excellent resistance to drinking and service water; very good cold formability and good hot formability; insensitive to non-oxidizing acids and neutral salt solutions; good for polishing, electroplating and tinning; excellent longevity;

• density 8.94 g/cc; melting point 1083 °C; thermal conductivity 305 W/mK; tensile strength 240-300 N/mm²;

• Available cut or made to measure.

Copper Granules 99.9% Pure Copper Cu Element 29 Purity Recycled 100gr-5kg

• Diameter from 2mm to 50mm. Length from 0.1 meter to 2 meters.

• Areas of application: heating and cooling technology (heating and cooling elements); Building (as decoration for interior lining and facades); electric lines; wire windings and chokes/coils.

• If your desired length/width is not listed, select the next larger length/width. Leave a comment on your order with the length/width you want. We cut according to your measurements.

• Dimensional tolerances: +/-2mm.

• Didn't find the sizes you wanted? Just contact us! We are happy to help you with your request.

• Fields of application: Construction industry; Decorative purposes; Automotive industry;

• Properties: good corrosion resistance; good workability; glossy appearance; excellent forgeability;

• density 7.9 g/cm3; tensile strength 700 Rm; modulus of elasticity 200 kN/mm²;

• Didn't find the sizes you are looking for? Just contact us! We will be glad to help you with your request.

• Fields of application: Electrical industry; mechanical engineering; chemical industry; gas and water installation; heating and air conditioning technology; plant and apparatus engineering;

• Properties: good durability; high corrosion resistance; very good weldability and brazeability; good thermal conductivity; excellent formability; good electrical conductivity;

• length tolerance +/-2mm.

• Didn't find the sizes you are looking for? Just contact us! We will be glad to help you with your request.

• Cu-ETP; EN CW004A.

• Areas of application: Hobby area & handicrafts; Decoration; Windings & electrical conductors; Contacts, terminals & switches.

• Density 8.93 g / cm³; Melting point 1083 ° C; Thermal conductivity 394 W / (m · K); electr. Resistance 0.018 Ω mm² / m; electr. Conductivity 57 S / m.

• Dimension tolerances: +/- 2mm.
